Prevost DPF Series – Retractable Polyurethane Hose Reel

Description

Prevost DPF Series – Retractable Polyurethane Hose Reel

The Prevost DPF Series is a premium, industrial-grade closed hose reel system designed to deliver compressed air efficiently while maintaining a safe and organized workspace. Encased in a rugged, epoxy-coated steel housing, this unit features a high-flexibility Polyurethane (PU) hose that offers superior maneuverability compared to traditional rubber or PVC hoses.

Engineered for safety and longevity, the DPF series prevents trip hazards and hose damage by automatically retracting the line when not in use. It is the ideal solution for workshops, assembly lines, and garages where floor space is at a premium and workflow efficiency is paramount.

Key Features & Benefits

• High-Flex Polyurethane Hose: The reel is pre-loaded with Prevost’s signature PU hose. This material is lighter than rubber and significantly more flexible than PVC, resisting kinks and abrasion while retaining its shape memory even after thousands of cycles.
• Controlled Safety Retraction: Unlike “mousetrap” reels that snap back dangerously fast, the DPF series features a controlled return mechanism. It guides the hose back into the casing at a safe, steady speed, preventing injury to the operator or damage to nearby equipment.
• Rugged Steel Casing: The internal components are protected by a hot-dip galvanized steel shell with a UV-resistant electrostatic powder coating, ensuring the reel withstands harsh industrial environments and accidental impacts.
• Full-Flow Swivel: Equipped with a high-flow internal swivel that ensures air volume is not restricted, allowing tools to operate at peak performance even when the hose is fully extended.
• Ergonomic Operation: The ratchet stop mechanism allows the user to lock the hose at any desired length, relieving tension while working. A simple tug releases the lock for retraction.
• 180° Swivel Bracket: Comes standard with a wall/ceiling mounting bracket that pivots 180°, allowing the hose to follow the operator around the room without dragging or bending at sharp angles.

Technical Specifications

• Part Series: DPF (Industrial Closed Reel)
• Hose Material: Braided Polyurethane (PU)
• Casing Material: Epoxy-Coated Galvanized Steel
• Operating Pressure: Up to 174 PSI (12 bar)
• Operating Temperature: +5°F to +104°F (-15°C to +40°C)
• Flow Rate: High flow capacity (e.g., ~29 CFM for 10mm ID models)
• Included: Input whip hose (1 meter) for connection to the main supply.

Ideal Applications

• Automotive Workshops: providing air to impact wrenches and tire inflators without cables cluttering the floor.
• Assembly Lines: Overhead installation for pneumatic screwdrivers and assembly tools.
• General Maintenance: “Wash down” or “Blow down” stations where the hose needs to be stored away cleanly after use.

Prevost DPF Hose Reels Series – Industrial Type – Polyurethane Hose – Technical specifications

• Technology :Pipe locked with ratchet stop
• Max operating pressure :174 psi
• Construction :Epoxy-coated steel case
• Connection :3.3 ft of inlet supply hose

180 deg. swiveling bracket
Inlet: G 3/8 F1 m. hose
Pressure: 12 bar
Temperature:5 deg. F to105 deg. F

Prevost DPF Series – Industrial Type – Polyurethane Hose Dimensions
