Prevost High-Pressure (HP) Hose Reel
Price range: $714.54 through $1,409.40
- Description
- Additional information
- Dimensions
Description
Prevost High-Pressure (HP) Hose Reel
Industrial Power for Heavy-Duty Lubrication & Cleaning
Tackle the toughest lubrication and maintenance jobs with confidence using the Prevost High-Pressure (HP) Hose Reel. Engineered to withstand extreme operating pressures (up to 5,800 PSI / 400 Bar), this reel is the ultimate solution for dispensing grease, hydraulic fluids, and high-pressure water in harsh industrial environments.1
Safety and durability are paramount when handling high pressure. That’s why the Prevost HP series features a reinforced steel drum with a corrosion-resistant epoxy powder coating. The heart of the system is a precision-machined, high-pressure swivel joint that ensures smooth fluid delivery without leaks or binding, even under maximum load. Whether you are servicing heavy earth-moving equipment or running a high-volume automotive shop, this reel keeps your dangerous high-pressure lines organized, protected, and off the floor.
Key Features & Benefits
- Extreme Pressure Capability: Built to safely handle pressures up to 5,800 PSI (400 Bar), making it ideal for chassis grease and hydraulic systems.2
- Rugged Steel Construction: The heavy-gauge steel frame and drum are stamped and welded for maximum rigidity, resisting flexing and deformation during use.
- Double-Braided Hose: typically equipped with a steel-reinforced (2SN) rubber hose designed to resist bursting, crushing, and abrasion.
- Reliable Ratchet System: Features a robust latching mechanism that locks the hose at your desired length, relieving tension so the operator can work comfortably.3
- High-Flow Swivel: The internal fluid path is designed to minimize restriction, ensuring thick grease or high-velocity fluids flow efficiently.
Technical Specifications
| Feature | Specification |
| Reel Type | Open Drum (Steel) or Enclosed (Series dependent) |
| Max Pressure | Up to ~5,800 PSI (400 Bar) |
| Fluid Compatibility | Grease, Hydraulic Oil, High-Pressure Water |
| Hose Construction | Double Wire Braid Reinforced (Synthetic Rubber) |
| Temperature Range | -4°F to +212°F (-20°C to +100°C) Verify per SKU |
| Mounting | Wall, Ceiling, or Floor |
Ideal Applications
- Heavy Equipment Maintenance: Greasing excavators, bulldozers, and mining trucks.
- Truck Fleet Service: Chassis lubrication for semi-trucks and buses.
- Industrial Manufacturing: Hydraulic fluid transfer for stationary plant machinery.
- High-Pressure Cleaning: Industrial washdown applications requiring extreme pressure (check specific hose rating).
Ergonomic Tip: When using this reel for grease dispensing, we highly recommend installing a Prevost Z-Swivel between the hose and the grease gun. This allows the gun to rotate freely, preventing wrist strain and hose twisting.
Additional information
| Weight | N/A |
|---|---|
| Dimensions | 19.094 × 18.701 × 9.331 in |
| Length (ft) | 50, 65 |
| Product Range | Hose Reels |
| Connection | 3/8 BSP, M22 |
| ID (in) | 5/16 in |
| Fluid Type | Water |
| PSI | |
| Option | Standard, Stainless Steel |
Prevost HP Hose Reel
| Reference | ID (in) | Length (ft) | Outlet | Swivel inlet BSPP female thread | Weight (lb) | A inch | B inch | C inch |
|---|---|---|---|---|---|---|---|---|
| DMO 0815HP | 5/16″ | 50′ | 3/8″ MBSP M22 x 1.5 | 3/8″ FBSP | 35.28 | 19.094 | 18.701 | 9.331 |
| DGO 0820HP | 5/16″ | 65′ | 3/8″ MBSP M22 x 1.5 | 3/8″ FBSP | 46.3 | 19.094 | 18.701 | 9.331 |
