Prevost DRF Series Hose Reel

Description

Prevost DRF Series Open Frame Automatic Hose Reel

The Prevost DRF Series represents the pinnacle of professional hose management, designed specifically for heavy-duty industrial environments where speed, safety, and reliability are non-negotiable. Featuring a robust open-frame design, the DRF series is engineered for high-frequency use, offering easy maintenance and superior heat dissipation for demanding pneumatic applications.

This series is the “workhorse” of the Prevost lineup, bridging the gap between medium-duty workshop reels and the ultra-large DGO series.

Key Features & Benefits

• Open Frame Accessibility: The exposed drum design allows for easy inspection of the hose and simplifies cleaning or maintenance. It also prevents debris from becoming trapped inside a housing.
• Automatic Spring Return: A high-tensile strength internal spring provides smooth, consistent retraction. The multi-position ratchet allows you to lock the hose at the desired length with minimal effort.
• Built-in prevoS1 Safety: Comes standard with the industry-leading prevoS1 safety coupling. This ensures a leak-free connection and safe, one-button decompression to eliminate hazardous “hose whip.”
• Reinforced Steel Construction: The frame is built from heavy-gauge galvanized steel with a high-resistance electrostatic powder coating, providing excellent protection against corrosion and mechanical impact.
• Adjustable Guide Arms: The roller guide arm can be adjusted to various positions, allowing for versatile mounting on walls, ceilings, or floors while maintaining an optimal exit angle for the hose.

Technical Specifications

Performance & Durability

The DRF series is built to handle the rigors of professional life:

• Fluid Compatibility: While primarily used for compressed air, specific DRF variants are available for water and oil distribution.
• Reduced Friction: The 4-roller hose guide assembly minimizes friction and wear on the hose jacket, significantly extending the life of the hose even with frequent lateral pulling.
• Full Flow Path: The internal swivel and shaft are designed to maintain a high flow rate, ensuring your air tools (like 1/2″ impact wrenches) operate at peak torque.

Ideal For:

• Heavy-duty automotive service centers.
• Industrial manufacturing and assembly plants.
• Tire shops and fleet maintenance bays.
• Large-scale woodworking and metal fabrication shops.

180 Degree swiveling bracket
Inlet: 3.3 ft hose
Outlet: with prevoS1 safety quick coupling
Temperature: 5 Degrees F to 149 Degrees F
Pressure: 175 psi
