Description

Prevost DMP Series Manual Steel Hose Reel

The Prevost DMP Series is a rugged, manual-retraction hose reel designed for professionals who prioritize simplicity, portability, and high-capacity air delivery. Built with a heavy-duty steel frame, the DMP series offers a dependable alternative to automatic reels, providing a stable “stand-up” or wall-mounted solution for larger hose lengths that require manual control.

It is particularly effective in high-traffic workshops or construction sites where a stationary automatic reel might be impractical or where a portable, high-flow air supply is needed across a large area.

Key Features & Benefits

• Dual-Mount Versatility: The DMP is designed as a free-standing unit with a wide, stable base for floor use, but it also features integrated mounting points for permanent wall installation.
• Heavy-Duty Build: Constructed from hot-dip galvanized steel and finished with a UV-resistant polyester powder coating, ensuring the frame remains corrosion-free even in damp or outdoor environments.
• High-Performance Hose: Typically equipped with a lightweight, flexible Polyurethane (PU) hose that is abrasion-resistant and maintains flexibility in temperatures ranging from -4 to +70 °C
• Manual Control: Features a foldable, ergonomic crank handle that allows for smooth, controlled winding without the complexity of a spring-return mechanism.⁷
• Safety Included: Standard models come pre-fitted with a prevoS1 safety quick coupling, which allows for a one-push connection and prevents dangerous hose whip during disconnection.⁸

Technical Specifications

Available Models (Common Configurations)

The DMP series is primarily distinguished by hose diameter and length to suit different tool requirements:

• DMP 0830: 8mm ID / 12mm OD hose, 30m (98 ft) length. Best for standard air tools.
• DMP 1025: 10mm ID / 14mm OD hose, 25m (82 ft) length. Best for high-consumption tools like impact wrenches.

Why choose manual? Manual reels like the DMP series are often preferred for very long hose lengths (up to 30 meters) where the weight of the hose can sometimes strain automatic spring-return mechanisms, or where “portable” air is required to move from one side of a facility to the other.
