Prevost PPS1 Connection Clamps & Flanges (CC Concept)

Description

Prevost PPS1 Connection Clamps & Flanges (CC Concept)

Industrial Strength Connections for Large Diameter Piping.

When your compressed air system scales up to high-volume distribution, you need a connection technology that matches the demand. The Prevost PPS1 “CC Concept” (Connection Clamp) range is engineered specifically for larger diameter aluminum pipes (Ø 50mm, 63mm, 80mm, 100mm and 160mm), providing a robust, modular, and leak-free alternative to traditional heavy steel flanges.

Replacing standard push-to-connect fittings used on smaller diameters, the CC Concept utilizes a high-performance clamping flange system. This design ensures maximum structural integrity and sealing power for main headers and industrial supply loops where pressure loads and physical stresses are highest.

Key Features & Benefits

• Modular “CC” Technology: The system separates the sealing mechanism from the mechanical grip. Stainless steel “CC” clamps bite firmly into the pipe grooves (created with the PPS tool), while separate flange gaskets ensure a bubble-tight seal. This allows for incredibly secure connections that are also easy to disassemble if the system needs to be modified.
• Compact & Lightweight: Traditional steel flanges are heavy and bulky.¹ The Prevost CC design uses lightweight, high-strength aluminum and composite materials, significantly reducing the load on your ceiling suspension structure.
• Zero Leak Guarantee: The dual-gasket design and precision-machined flange faces ensure leak-free performance, even under the dynamic vibration of heavy industrial compressors.
• Safety & Security: The visual nature of the external clamps gives installers immediate confirmation that the joint is locked and secure. The robust bolting mechanism prevents accidental disconnection under pressure.
• Corrosion Resistant: Built entirely from aluminum, stainless steel, and high-grade polymers, these flanges are immune to rust, ensuring clean air delivery for decades.

Technical Specifications

Ideal Applications

• Compressor Room Headers: Connecting large dryers, receivers, and compressors to the main plant loop.
• Main Distribution Loops: Running the primary 3″ or 4″ backbone through large manufacturing facilities.
• Heavy Industrial Zones: Environments with high vibration or physical stress where push-fittings might not offer enough rigidity.

Why Choose the CC Concept?

For large pipes, you need more than just friction holding them together. The Prevost CC Concept combines the mechanical security of a bolted flange with the lightweight ease of aluminum piping. It is the safest, most reliable way to manage high-volume airflow in an industrial setting.
