Prevost PPS Tapping Flange Square Profile

Description

Prevost PPS SQFL – Square Profile Tapping Flange

Create Custom Air Drops Instantly, Anywhere. The Prevost PPS SQFL Tapping Flange is the ultimate problem-solver for the Prevost PPS Square (SQ) aluminum system. It allows you to tap directly into the flat face of the square profile to create a new compressed air outlet at any point along the beam, eliminating the need to disassemble your existing workstation or rely solely on end-point connections.

• Retrofit Ready: Perfect for expanding existing workstations. If you need to add a new tool station or air drop in the middle of a long runner, simply drill the profile and install this flange—no pipe cutting required.
• Leak-Proof Seal: Designed with a specialized integrated gasket that compresses against the flat surface of the square aluminum profile, ensuring a 100% airtight seal that holds up to system pressure and vibration.
• Versatile Threaded Outlet: Converts the drilled hole into a standard Female NPT Thread (e.g., 1/2″), providing a universal connection point for quick couplers, elbows, or ball valves.
• Secure Mounting: Attaches firmly to the profile using rigid fasteners, ensuring the outlet can withstand the mechanical stress of plugging and unplugging air hoses daily.
• Low-Profile Design: Sits flush against the beam, maintaining the clean lines of your assembly bench and preventing snagging hazards.

Installation is Simple:

1. Drill a hole in the square profile at the desired location.
2. Position the flange over the hole.
3. Tighten the mounting screws to compress the seal.
4. Screw in your coupler or drop line.

This flange gives you the freedom to put compressed air exactly where your process needs it, without the constraints of the original frame design.
