Prevost Micro Air MF Series Clamps & Mounting

Description

Prevost Micro Air MF Series Clamps & Mounting

The Modular Foundation for High-Purity Air Systems

The Prevost MF Series Mounting System is the essential hardware required to professionally install and scale your Micro Air filtration system. Because high-purity air often requires a “train” of multiple filters (Pre-filter, Coalescer, and Activated Carbon), these specialized clamps and brackets allow you to join units together into a single, rigid, leak-free manifold.

Designed for stability and ease of maintenance, this mounting hardware ensures your filtration investment is securely supported and properly aligned.

Key Components

1. MF Series Joining Clamps (The “Coupler”)

The joining clamp is what makes the Micro Air series truly modular. It features a precision-molded profile that locks two filter heads together.

• Perfect Alignment: Ensures the internal O-rings are perfectly seated between units to prevent high-pressure leaks.
• Rapid Serviceability: Allows you to remove or add a filter stage (like adding an MFC Carbon filter for a specific job) without re-plumbing the entire hard-pipe system.

2. Heavy-Duty Wall Mounting Brackets

These brackets are designed to take the weight of a multi-stage filtration assembly, especially when bowls are full of collected moisture.

• Vibration Dampening: Provides a rock-solid anchor point that isolates the filtration stages from the vibrations of the compressor or industrial machinery.
• Surface Offset: Positions the filters at the ideal distance from the wall, allowing enough clearance for the operator to easily unscrew the bowls for element changes.

Key Features

• Modular “Lego-Style” Assembly: Allows you to build custom filtration banks (e.g., MFM + MFB or MFM + MFB + MFC) in minutes.
• Corrosion-Resistant Finish: Treated with the same high-grade protective coating as the Micro Air filter bodies to withstand humid and industrial environments.
• High Pressure Rating: Engineered to maintain a total seal even at the maximum operating pressures of the Micro Air series (up to 232 PSI).
• Minimal Footprint: The slim-profile clamps keep the filter stages tightly packed, saving valuable wall space in tight shop environments.

Technical Specifications

Feature	Specification
Compatibility	Prevost Micro Air (MFM, MFB, MFC Series)
Material	Reinforced Technical Polymer / High-Grade Steel
Max Pressure	Matches Filter Rating (Up to 232 PSI)
Configuration	Single, Double, or Triple Bank Mounting
Installation	Basic hand tools required

Why Proper Mounting Matters

Micro Air filters are precision instruments. If they are left hanging by the air pipes, the stress on the threaded ports can lead to hairline cracks or slow leaks. Using the MF Series Clamps and Brackets ensures that the weight of the system is supported by the building’s structure, not your plumbing. Furthermore, it creates a professional, organized “Air Station” look that reflects the quality of your work.

Ideal Applications

• Multi-Stage Filtration Banks: Essential for connecting 2 or 3 filters in a row for automotive painting.
• Machine Integration: Mounting filtration units directly to CNC frames or industrial equipment.
• Clean Room Setups: Ensuring an organized, easy-to-clean air preparation area.
