Prevost Filter-Regulator

INTEGRATED PRESSURE GAUGE
BARB-TYPE OUTLET

Inlet pressure: 12 to 145 psi, Outlet pressure : 10 to 120 psi, Temperature: 40 deg F to 120 deg F

Module	T1	L1	L2	L3	L4	L5	L6	L8	L9	L10	ËB1	B2	B3	B4
ATU M2585200	1/8″ FNPT	215 mm	56 mm	30 mm	58.5 mm	137 mm	159 mm	4.5 mm	25 mm	40 mm	28 mm	M30x1.5 mm	42 mm	58 mm
ATU M2585201	1/4″ FNPT	215 mm	56 mm	30 mm	58.5 mm	137 mm	159 mm	4.5 mm	25 mm	40 mm	28 mm	M30x1.5 mm	42 mm	58 mm
ATU M2585202	3/8″ FNPT	302 mm	84 mm	45.5 mm	89.5 mm	196 mm	217 mm	7 mm	30 mm	62 mm	42.5 mm	M45x1.5 mm	62 mm	77.5 mm
ATU M2585203	1/2″ FNPT	302 mm	84 mm	45.5 mm	89.5 mm	196 mm	217 mm	7 mm	30 mm	62 mm	42.5 mm	M45x1.5 mm	62 mm	77.5 mm
