Prevost Female Thread Single Wall Manifold High Flow Interchange

Description

Prevost Female Thread Single Wall Manifold: High Flow Interchange (ESI Series)

The Prevost ESI Single Wall Manifold is the ultimate distribution hub for high-performance pneumatic systems. Engineered for professional workshops that demand both safety and maximum air volume, this manifold features integrated Prevo S1 safety couplings in a streamlined, wall-mounted configuration.

Designed specifically for the European High Flow (7.2–7.4mm) profile, this manifold allows you to turn a single air drop into multiple high-capacity workstations without sacrificing tool power or operator safety.

Key Performance Features

• Integrated Prevo S1 Safety: Each port is equipped with Prevost’s patented venting technology. A single press of the green button exhausts downstream pressure before releasing the tool, eliminating dangerous hose whip and ensuring a safe disconnect every time.
• High Flow “Green Button” Profile: Designed to provide an unrestricted path for air delivery. This manifold ensures that high-demand tools—like 3/4″ impact wrenches, high-volume spray guns, and large grinders—receive the CFM required to operate at peak torque.
• Single-Wall Space-Saving Design: The compact, low-profile body mounts flush to walls or machine frames. It organizes your workspace by consolidating multiple connections into one central, easy-to-access location.
• Non-Marring & Durable Housing: The composite coupling bodies are scratch-resistant and anti-static, making this manifold ideal for automotive paint booths, detailing bays, and fine woodworking shops.
• Leak-Free Manifold Block: The solid internal construction is designed for 100% airtight performance, reducing compressor cycling and lowering energy costs for your facility.

Technical Specifications

Ideal Applications

• Centralized Workstations: Perfect for assembly lines where multiple operators need to pull air from a single main line drop.
• Automotive Service Bays: Mount one between two lifts to provide high-flow air for impact tools and tire inflators simultaneously.
• Industrial Machine Feeds: Use as a distribution point on large machinery to power various pneumatic actuators and hand tools.

Installation Tip

For the highest possible efficiency, ensure your supply line matches the inlet diameter of the manifold. To complete the high-flow circuit, always use Prevost ERP Series male plugs on your tool leads.
