Prevost Female Thread Double-Wall Manifold – Industrial Interchange

Description

Prevost Female Thread Double-Wall Manifold – Industrial Interchange

Maximum Productivity for High-Traffic Workstations

The Prevost Female Thread Double-Wall Manifold is the ultimate air distribution solution for high-density workspaces. By featuring outlets on opposite sides of the manifold block, this “Double-Wall” configuration allows you to service two different work areas or benches from a single overhead or wall-mounted drop. Engineered for durability and high flow, it is the professional choice for organized, multi-user pneumatic systems.

Key Features

• Double-Sided Accessibility: The dual-row configuration maximizes tool connectivity without increasing the manifold’s footprint. It allows air lines to run in opposite directions, preventing hose tangling and clutter in busy corridors or between back-to-back workbenches.
• Heavy-Duty Aluminum Block: CNC-machined from premium-grade aluminum for a high strength-to-weight ratio. The body is treated to resist corrosion, ensuring the internal air passages remain clean and free of debris.
• Integrated Industrial Sockets: Comes pre-fitted with Prevost’s high-performance Industrial Interchange (ISO 6150 B) female couplers. These are compatible with all standard North American “M-Style” plugs.
• High-Volume Air Reservoir: The “Double-Wall” body acts as a mini-receiver, stabilizing air pressure across all ports even when multiple high-draw tools (like 3/4″ impact wrenches) are triggered simultaneously.
• Secure Mounting Design: Features integrated mounting holes for a rock-solid installation on pillars, walls, or tool rails, ensuring the manifold stays stationary even when hoses are being pulled or swapped.

Technical Specifications

Why Choose a Double-Wall Manifold?

Standard single-row manifolds often lead to “hose crossing” when multiple operators try to plug in. The Double-Wall design solves this by separating the connection points physically. When outfitted with Prevost S1 Safety Couplers, this manifold becomes a “safety hub,” allowing users to disconnect tools with a single button press—eliminating dangerous hose whip in tight, multi-person spaces.

Ideal Applications

• Back-to-Back Workstations: Service two separate assembly lines from one central pillar.
• Central Shop Aisles: Mount on a center post to provide air access to both the left and right service bays.
• Mobile Service Trucks: Maximize port density in confined spaces where wall real estate is limited.
• Industrial Labs: Provide clean, organized air distribution for multiple testing stations.
