Prevost Compressed Air Multi-Swivel
3D Freedom of Movement for Maximum Ergonomics
The Prevost Multi-Swivel (also known as the “Universal Swivel”) is the ultimate solution for pneumatic tool ergonomics. While standard swivels only rotate on a single axis, the Multi-Swivel features a sophisticated dual-axis ball-and-socket design. This allows the coupler to rotate 360° and tilt simultaneously, providing a full range of three-dimensional motion.
By allowing the hose to drop straight to the floor regardless of how the tool is angled, it eliminates hose “fighting,” wrist strain, and the dangerous kinking that restricts airflow.
Key Features
- Dual-Axis Articulation: Combines a 360° rotation with a high-angle tilt. This “universal joint” action ensures the air hose never pulls against the operator’s wrist, making even heavy impact wrenches feel agile.
- High-Flow Internal Geometry: Unlike restrictive “swivel elbows,” the Prevost Multi-Swivel is engineered with a wide internal bore to ensure zero pressure drop. Your high-demand tools (grinders, sanders, and nut runners) receive the full CFM required for peak torque.
- Safety S1 Compatibility: Often paired with the Prevo S1 Safety Coupler, this assembly provides the safest, most ergonomic connection point in the industry—combining “zero-whip” venting with effortless maneuverability.
- Robust Metallic Construction: Built from high-strength, chrome-plated steel or treated aluminum to withstand the constant movement and “bumping” of an active assembly line or automotive shop.
- Leak-Free Precision Seals: Equipped with high-performance internal O-rings that remain perfectly airtight even under constant 3D rotation and maximum system pressure.
Technical Specifications
| Feature | Specification |
| Rotation | 360° Circular / Multi-Angle Tilt |
| Max Pressure | 174 PSI (12 bar) |
| Material | Chrome-Plated Steel / Aluminum |
| Connections | Male/Female NPT (Typically 1/4″ or 3/8″) |
| Temperature Range | 15°F to 160°F (-10°C to +70°C) |
| Compatibility | All Industrial Interchange Plugs/Couplers |
The “Ergonomic Advantage”
Repetitive Strain Injuries (RSI) are a major concern in industrial environments. A rigid air connection forces the operator’s wrist to support the weight and “spring” of the air hose. The Prevost Multi-Swivel acts as a mechanical wrist, absorbing the tension of the hose so the operator doesn’t have to. This leads to higher precision, less fatigue, and a significantly safer work environment.
Ideal Applications
- Automotive Assembly: Perfect for under-car work or interior assembly where tools must be held at awkward angles.
- Sanding & Polishing: Allows the hose to follow the movement of the sander without “catching” on the edges of the workpiece.
- Impact Tools: Reduces the vibration transferred from the tool to the hose, extending hose life and protecting the operator.
- Overhead Air Drops: Prevents “pigtail” hoses from tangling and spiraling when tools are pulled down to a workbench.
