Prevost Brass Push-On Fitting (Stoflex Hose Only)

Description

Prevost Brass Push-On Fitting (Stoflex Hose Only)

The Clamp-Free Solution for a Scratch-Free Finish.

Achieve a smooth, streamlined connection with the Prevost Brass Push-On Fitting, designed exclusively for use with Prevost Stoflex Anti-Static Hose. Unlike standard barbed fittings that require bulky worm-gear clamps or crimped ferrules, this specialized fitting utilizes “Push-Lock” technology to secure the hose.

The result is a sleek, low-profile connection with no sharp edges and no protruding clamps. For paint shops and auto body centers, this is critical—it eliminates the risk of a metal hose clamp dragging across and scratching a freshly painted fender or clear coat.

Key Features & Benefits

• Clamp-Free “Push-Lock” Security: The barb geometry is engineered to grip the internal reinforcement braid of the Stoflex hose. As internal air pressure increases, the hose contracts around the barbs, tightening the seal naturally. No clamps are required.
• Scratch-Free Profile: With no metal bands, screws, or sharp crimps exposed, the connection is perfectly smooth. This protects delicate surfaces (vehicles, furniture, glass) from accidental damage while the hose is dragged during use.
• Maintains Anti-Static Continuity: Machined from solid brass, this fitting ensures a conductive path between the anti-static Stoflex hose and your air tool or coupler, allowing static electricity to dissipate safely to the ground.
• Field Reusable: If the hose is damaged, simply slice the hose off the barb and re-insert the fitting into a fresh section. It is a permanent solution that is easy to service in the field.
• High-Flow Bore: The thin-wall brass construction allows for a larger internal diameter than many crimped fittings, ensuring maximum airflow to your spray gun or tool.

Technical Specifications

Ideal Applications

• Paint Spray Booths: The #1 choice for painters who cannot risk a hose clamp scratching a customer’s car.
• Furniture Finishing: Protects wood and lacquer finishes from abrasion.
• Assembly Lines: prevents snagging on machinery or products.

Important Safety Note

Do not use hose clamps with this fitting. This fitting is designed specifically for the dimensions and braid angle of Prevost Stoflex (and compatible push-on style) hoses. Using standard rubber air hose that is not rated for “Push-Lock” applications may result in the hose blowing off under pressure.
