Prevost 27202 Metal Nozzle

$15.60$55.45

SKU: N/A Category:
Clear
View cart

Description

OSHA VENTURI METAL NOZZLE BLOW GUN

NPT female thread Air consumption (at 87 psi (cfm)) Blowing force (at 87 psi (Ozf)) Dynamic pressure (at 87 psi at 4″)(psi) Reference
1/4″ FNPT 6.6 7.5 32 27202 MTLOSHA

METAL NOZZLE BLOW GUN STANDARD AND LIMITED FLOW

NPT female thread Air consumption (at 87 psi) Noise level (at 87 psi(dBA)) Blowing force (at 87 psi (Ozf)) Dynamic pressure (at 87 psi at 4″)(psi) Reference
1/4″ FNPT 13.5 cfm 83 13 18 27202 MTL
1/4″ FNPT 5.3 cfm 73 4.4 11 27202 MTLBP3

RUBBER TIP

Nozzle Construction Reference
Bent 4″ with

rubber tip &

1/4″ NPT

Metal tip blow gun with non-scratch nozzle 27202 MTLRT

METAL

NPT female thread Air consumption (at 87 psi) Noise level (at 87 psi (dBA)) Blowing force Dynamic pressure (at 87 psi at 4″)(psi) Length (tube (in)) Reference
1/4″ FNPT 8.8 cfm 86 9.3 25 Bent 13″ 27202 MB13
1/4″ FNPT 8.5 cfm 86 8.6 22 Bent 20″ 27202 MB20
1/4″ FNPT 8.8 cfm 86 9.3 25 Straight 13″ 27202 MS13
1/4″ FNPT 8.5 cfm 86 8.6 22 Straight 20″ 27202 MS20

OSHA METAL

NPT female thread Air consumption (at 87 psi) Noise level (dBA) Blowing force (at 87 psi (Ozf)) Dynamic pressure (at 87 psi at 4″)(psi) Length (tube (in)) Reference
1/4″ FNPT 6.2 cfm 82 7.2 36 Bent 13″ 27202 MB13OSHA
1/4″ FNPT 5.5 cfm 81 6.6 36 Bent 20″ 27202 MB20OSHA
1/4″ FNPT 6.3 cfm 83 7.7 35 Bent 40″ 27202 MB40OSHA

Additional information

Type

OSHA VENTURIMETAL STANDARD, METAL STANDARD, METAL LIMITED FLOW, RUBBER TIP, BENT 13 IN, BENT 20 IN, STRAIGHT 13 IN, STRAIGHT 20 IN, OSHA BENT 13 IN, OSHA BENT 20 IN, OSHA BENT 40 IN, NEUTRAL
