Prevost Conex Unequal Multiple Tee

Description

Prevost Conex Unequal Multiple Tee

High-Density Manifolding for Streamlined Air Distribution

The Prevost Conex Unequal Multiple Tee is a high-efficiency distribution block designed to split a primary air supply into multiple branch lines of a smaller diameter. This “all-in-one” fitting replaces the need for complex “daisy-chained” tees, providing a centralized hub that reduces leak points and significantly cleans up the visual profile of your pneumatic system.

Engineered for industrial automation and control cabinets, this multiple tee allows you to feed several actuators or sensors from a single main drop with total flow balance.

Key Features

• Centralized Distribution: Features one large-diameter “main” inlet/outlet path and multiple smaller-diameter “branch” ports. This configuration is ideal for transitioning from a high-volume supply line to several precision pilot or actuator lines.
• Instantaneous “Grip” Technology: Every port—both the main line and the branches—is equipped with Prevost’s signature stainless steel gripping rings. Installation is 100% tool-free; simply push the technical tubing (PU, PA, or PE) in for a secure, vibration-proof seal.
• Space-Saving Manifold Design: By consolidating multiple junctions into a single body, this fitting reduces the overall footprint of your pneumatic circuit. It is the perfect solution for tight enclosures where space for individual fittings is limited.
• Optimal Flow Dynamics: The internal chamber is designed to distribute pressure equally across all branch ports, ensuring that downstream components receive consistent air volume for synchronized operation.
• Robust Composite Construction: Manufactured from high-impact technical polymer, the Multiple Tee is naturally resistant to corrosion, moisture, and common industrial oils, making it much lighter and more versatile than traditional brass manifolds.

Technical Specifications

Feature	Specification
Connection Type	Unequal Multiple Tee (Reducer Manifold)
Main Port Sizes	Typically 6mm to 12mm
Branch Port Sizes	Typically 4mm to 8mm
Max Operating Pressure	145 PSI (10 bar)
Vacuum Rating	-28 inHg
Temperature Range	32°F to 140°F (0°C to +60°C)

The Efficient Alternative to “Spaghetti” Tubing

In professional pneumatic design, minimizing connections is key to system longevity. Every traditional tee added to a line introduces two more potential leak points. The Prevost Conex Unequal Multiple Tee eliminates this risk by using a single-piece molded body for all branches. This results in a “cleaner” build that is easier to troubleshoot, easier to bundle into protective sleeving, and far more aesthetically professional.

Ideal Applications

• Control Cabinets: Distributing a main air supply to a bank of solenoid valves or pressure switches.
• Machine Tooling: Feeding multiple cooling nozzles or air-driven spindles from a single supply hose.
• Automated Assembly: Powering a series of small pneumatic grippers or cylinders on a multi-stage pick-and-place machine.
• Pneumatic Logic: Creating a central signal hub for air-logic control systems.

Installation Tip

To ensure a perfect seal across all ports, always use a dedicated tube cutter to ensure every tube end is cut square. When inserting the tubing, push firmly until it seats past the internal O-ring. A quick “pull-test” on each line will confirm the gripping mechanism is fully engaged before pressurizing the system.
